GTREX - The Urban Bicycle - Reimagined

PRE-ORDER NOW!

Start your adventure right from your front door.

The KRUCH GTREX is the product of 2 years of planning, testing, and prototyping. A product born from trial and error, and ultimately - refinement. Locally here in Calgary, a team of bicycle enthusiasts and specialists obsessed over the details to bring our version of the ultimate urban bicycle to fruition. And now, in a few short months, you can have one too.

GTREX 001 in it's natural habitat

PRE-ORDER NOW!

It started with a close friend posing the question: "If one were to view the urban landscape as rideable terrain, what would the ultimate bicycle be for navigating that landscape?" That question spawned some serious discussion, deep thought, and drove an obsession about geometry, fork offset, standover, and other critical criteria. The idea stuck.

Once the initial geometry and specifications were settled on, a factory partner was enlisted to build several raw prototype frames, forks, and bars. The components were then finished in Calgary - final welding, braze-ons added, faced and chased, painted/powder-coated, and then assembled. One test mule was hand-built from stainless steel for comparison purposes on ride quality. We now had three complete prototype GTREX bikes in three sizes.

After extensive traveling with the bikes - and many many kilometers put on the bikes in various terrains and conditions, we are very happy with the results.

The first testing occurred in Calgary in March 2024, but the first travel test occurred in Cleveland, Ohio - for the solar eclipse that occurred on April 8th, 2024.

The Author clapping immediately after the Great North American Eclipse - Cleveland, Ohio - April 7th, 2024

For the entirety of the 2024 season, the test bikes have been loaned out, ridden daily, and subjected to everything we could throw at them. From pathways to pump tracks to pubs, and everything in between - we love this bike. Butted steel tubing provides a compliant ride, and relaxed pedaling geometry means that adventures are comfortable and can go on for many hours and kilometers.

The GTREX is available as a complete bike (3 models) or a frameset, or as a frameset/fork/bar combination.

Designed in Calgary, finished in Calgary, and assembled in Calgary - we are very proud to present the GTREX.

Key Features:

• 29" wheels - ability to fit up to a 29 x 2.3" tire.

• Steel construction - premium grade butted 4130 chromium molybdenum steel, TIG welded.

• Tucked - all 3 sizes come with a very tucked rear end - 425mm chainstay length.

• Dropper - all three models come with a dropper post.

• Dropouts - sliding/adjustable.

• Standover - drop the seat post and drop in - this bike is built for the pump track.

• Fork - steel, segmented style, suspension corrected to a 120mm travel fork. Triple bosses on each stanchion, designed for a front bag mount or a light bar. 45mm offset. Compliant and versatile, and built to last.

• Bar - steel, 780mm wide, 100mm rise, 9 degree sweep - designed for comfort and maximum shredability.

• Parts - each of the three models comes with a carefully curated list of robust parts from our partners at Race Face, Shimano, Sun Ringle, Maxxis and Manitou. These builds are made to last!

• Versatility - The bike has features that make it easy to take bikepacking, easy to hit the pump track, ready for gravel roads, and much more. It's the everything bike, although we hestitate to call it the "quiver killer", it's pretty close.

• Customizable - For an upcharge - add additonal bottle bosses, rack mounts, or pick a completely custom colour. It's up to you!

• Unique - There will only ever be 55 GTREX bikes. Each bike comes with a stainless steel tag and, it's number from 1 to 55.




  Note: Each GTREX comes with a colour matched G-fork and G-bar, except the tactical edition - which comes with a 120mm travel suspension fork.




GTREX prototype with it's factory G-Bar and G-Fork

Geometry:

	Medium	Large	Extra Large
Stack	623mm	653	655mm
Reach	450mm	470mm	510mm
Top Tube Length	602mm	630mm	663mm
Seat Tube Length	405mm	425mm	445mm
Bottom Bracket Drop	50mm	50mm	50mm
Chain Stay Length	425 mm	425 mm	425mm
Head Tube Angle	69 degrees	69 degrees	69 degrees
Seat Tube Angle	76 degrees	75.5 degrees	75 degrees
Head Tube Length	117mm	149mm	151mm
Recommended Rider Height	5 ft 5" to 5ft 8"	5ft 9" to 6ft 0"	6ft 1" to 6ft 6"

G-Fork Specifications

Axle to Crown	Offset	Axle standard	Brake Standard
505mm	45mm	110mm boost	Post Mount 160mm

G-Bar Specifications

Width	Rise	Sweep	Material
780mm	100mm	9 degrees	4130 Steel

Builds

	Single Speed Edition	GTREX	Tactical Edition
Fork	KRUCH G-Fork, colour matched	KRUCH G-Fork, colour matched	Manitou Mattoc Comp 29 Suspension Fork
Bars	KRUCH G-Bar, colour matched	KRUCH G-Bar, colour matched	KRUCH G-Bar, colour matched
Front wheel	Sun Ringle Duroc SD37 Comp 29, 110 x 15, tubeless ready	Sun Ringle Duroc SD37 Comp 29, 110 x 15, tubeless ready	Sun Ringle Duroc SD37 Comp 29, 110 x 15, tubeless ready
Rear wheel	Sun Ringle Duroc SD37 Comp 29 148 x 12, tubeless ready	Sun Ringle Duroc SD37 Comp 29 148 x 12, tubeless ready	Sun Ringle Duroc SD37 Comp 29 148 x 12, tubeless ready
Dropper Seat Post	Race Face Aeffect 160mm, Aeffect Lever	Race Face Aeffect 160mm, Aeffect Lever	Manitou Jack 160, 31.6mm, Manitou Lever
Tires	Maxxis Recon 29 x 2.25 Tan Wall	Maxxis Recon 29 x 2.25 Tan Wall	Maxxis Recon 29 x 2.25 Tan Wall
Saddle	49N Slimline	49N Slimline	49N Slimline
Headset	Cane Creek 40 series ZS44/EC44	Cane Creek 40 series ZS44/EC44	Cane Creek 40 series ZS44/EC44
Stem	RaceFace Chester 50mm	RaceFace Chester 50mm	RaceFace Chester 50mm
Grips	RaceFace Half Nelson	RaceFace Half Nelson	RaceFace Half Nelson
Crank	Shimano Cues, 175mm, 32T chainring	Shimano Cues, 175mm, 32T chainring	Shimano Cues, 175mm, 32T chainring
Bottom Bracket	Shimano MT-501	Shimano MT-501	Shimano MT-501
Brakes	Shimano MT-201 front and rear	Shimano MT-201 front and rear	Shimano MT-201 front and rear
Shifter	n/a	Shimano Cues Rapid-fire	Shimano Cues Rapid-fire
Derailleur	n/a	Shimano Cues 10 speed	Shimano Cues 10 speed
Cassette	n/a	Shimano Cues 10 Speed 11-13-15-17-20-23-28-34-41-48T	Shimano Cues 10 Speed 11-13-15-17-20-23-28-34-41-48T
Chain	Shimano HG-601	Shimano HG-601	Shimano HG-601
Available Colours	70s Van Purple Sparkle, Gold Star Yellow, Cran Apple.	70s Van Purple Sparkle, Gold Star Yellow, Cran Apple.	Flat Black Metallic, Sage Green

Swatches

We know you are going to love this bike as much as we do!
